Reliable Fidelity and Operation
The LD Systems HHD Single Handheld Dynamic Mic Wireless System features excellent noise rejection and consistent audio fidelity. The System includes an inaudible pilot tone which helps keep a strong connection between transmitter and receiver, whilst the cardiod polar pattern on the microphones rejects extraneous noise from unwanted sources. The squelch function also helps to eliminate unwanted noise and improve signal isolation even further. The 55 - 16,000 Hz frequency range and convenient handheld microphone makes the LD Systems HHD ideal for voice applications.
About LD Systems
LD Systems have quickly become a leading pro audio brand in only a decade of business. They have an extensive range of state-of-the-art products and continue to innovate, finding new ways to improve the possibilities of sonic performance and value. They provide an extensive range of accessories to protect and expand the applications of their products.
Highlights
- Diversity UHF wireless system
- Automatic channel scan
- Easy one-touch infrared frequency syncing
- Pilot tone squelch circuit
- Rugged enclosures
Technical Specifications
- Product type: Wireless Microphone Systems
- Type: Set
- Transmission frequency range: 863 - 865 MHz
- Weight: 0.94 kg
- LD Systems U308 R Receiver
- Product type: Wireless Microphone System Accessories
- Type: Receivers
- Modulation Type: FM
- Transmission frequency range: 823 - 832 MHz
- Channels: 12
- Groups: 1
- Antenna inputs: 2 x fixed
- Frequency response: 25 - 16,000 Hz
- Noise reduction: Squelch
- Transmission optimization: Pilot tone
- THD: < 0.3 percent
- Signal-to-noise ratio: 104 dB
- Audio output, balanced: XLR
- Controls: volume
- Audio output, unbalanced: 6.3 mm jack, switchable unbalanced output level
- Indicators: LCD display
- Operating voltage: 12 V DC - 18 V DC (500 mA), external power supply
- Max. output level: +10 dBu (Bal), +7 dBV (Unbal, Line), +2,5 dBV (Unbal, Instr) dBu
- Weight: 0.7 kg
- Other features: IR frequency synchronisation
- Width: 211 mm
- Height: 43 mm
- Depth: 120 mm
- Accessories (included): power supply
- LD Systems U308 MD Dynamic handheld microphone
- Type: Microphones
- Microphone type: Dynamic
- Directivity: Cardioid
- Frequency response: 55 - 16,000 Hz
- Rated HF output power: 10 mW
- Controls Power: On/Off
- Indicators: Power LED (Power ON: green)
- Operating voltage: 2 x AA battery
- Operating time: >10 h
- Length: 257 mm
- Diameter: 50 mm
- Weight: 0.235 kg
- Other features: Pilot tone
